| Amperage Rating | : | 4.8 A |
| Bearing Type | : | 130 gpm Flow Rate |
| Dimensions | : | 10-3/4 in L x 8-1/2 in W x 5-1/8 in H |
| Flow Rate | : | 130 gpm |
| Frequency Rating | : | 60 Hz |
| Impeller Type | : | Glass Filled PPS |
| Maximum Head | : | 20 ft |
| Maximum Pressure | : | 150 psi |
| Motor Speed | : | 3200 rpm |
| Power Rating | : | 2/5 hp |
| Series | : | PL-130/2 |
| Temperature Rating | : | 225 deg F |
| Type | : | Single Phase |
| Voltage Rating | : | 115 V |
Bell & Gossett SERIESPL™ Booster Circulating Pump, Single Phase, Series: PL-130/2, 130 gpm, 20 ft Maximum Head, 2/5 hp, 115 V, 4.8 A, 60 Hz, 150 psi Maximum, 3200 rpm Motor, Glass Filled PPS Impeller, 225 deg F, Ball Bearing, 10-3/4 in L x 8-1/2 in W x 5-1/8 in H
- B and G's powerful, dry-motor design delivers exceptional performance
- 25% more efficient than competition
- Precision-machined and balanced alloy steel rotor for superior performance
- Solid "Stiff-Shaft" design is constructed of high-strength alloy steel impervious to cracking caused by thermal stresses
- XL-11™ Precision-Crafted bearing system
- Permanently oil lubricated
- Completely maintenance free
- Advanced close-coupled design increases pump life and efficiency, assures dependable seasonal start-ups and can easily handle difficult water conditions
- Tough, durable seal system features a carbon/silicon carbide seal on a stainless steel shaft sleeve for long life and rugged operation
- Double sided stainless steel neck ring for optimum efficiency
- Cast iron booster body
- Stainless steel face plate
- Carbon steel shaft, stainless steel shaft sleeve
- Mechanical, carbon on silicon carbide seal
- Sealed precision steel ball bearing permanently lubricated motor bearings
- ODP motor
- EPDM elastomers
- 2 in NPT flanged connection
- Model PL-130/2 in
