| Audible Alert | : | 85 dB at 10 ft |
| Color | : | White |
| Dimensions | : | 14 to 140 deg F Operating Temperature |
| Display | : | LED |
| Humidity Rating | : | 0.95 |
| Includes | : | (1) RTS2 or RTS2-AOS Multi-Signaling Accessory, (1) Mounting Hardware Kit (Contains (2) Sets Of Mounting Screws And (1) Tamper Resistant Outer Cover Mounting Screw |
| Operating Temperature | : | 14 to 140 deg F |
| Warranty | : | 3 Years |
System Sensor® Innovair Flex® Multi-Signaling Unit, 85 dB at 10 ft Alert, 95% Humidity Rating, LED, 14 to 140 deg F Operating, White, 5.3 in H x 4.8 in W x 1.6 in D
- RTS2-AOS is a multi-signaling accessory, with strobe, designed to work with InnovairFlex 4-wire conventional duct smoke detectors, AOS stands for Add On Strobe
- Standby (green blink), trouble (amber), maintenance (amber blink) and alarm (red) LEDs to indicate detector status
- Keyswitch to select desired sensor, enable test/reset button and sensitivity reading
- Test/reset button
- Selectable continuous or temporal tone
- AOS add on strobe (included on RTS2-AOS model)
- Provisions for single or double gang box mounting
- Ability to discretely monitor two sensors when duct smoke detectors are configured in a 2 to 1 set up (See InnovairFlex duct smoke detector manual for reference)
- Sounder 85 dBA at 10 ft
- 20 to 29 VDC
- Strip terminal, 22 to 14 AWG wire connections
