Allied Commercial™ KCB036S4DN-P
Allied Commercial™ K-Series™ | 3 Ton Cooling | 208/230 V | 1 phase | Rooftop Packaged Electric Cooling Unit With Optional Electric Heat
Manufacturer: Allied Air Enterprises
Brand: Allied Commercial™
Part #: 333364
MPN: KCB036S4DN-P
UPC: 662551487541
CPN:
Min. Order Qty: 1
Qty Order Interval: 1
| Compressor Type | : | Scroll |
| Cooling Capacity | : | 36000 Btu/hr |
| Dimensions | : | 38-7/8 in H x 47 in W x 85-1/4 in D |
| EER Rating | : | 12.5 |
| Flow Rate | : | 1140 cfm |
| Fuse Size | : | 40 A |
| Material | : | Steel |
| Motor Rating | : | (1) 1/4 hp |
| Motor Type | : | Multi-Speed Blower |
| Number of Phases | : | 1 ph |
| Power Source | : | 2.9 kW 208/230 V 60 Hz 1 ph |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 14 |
| Series | : | K-Series |
| Sound Level | : | 74 dB |
| Type | : | Rooftop |
| Voltage Rating | : | 208/230 V |
| Warranty | : | 5 Years |
Allied Commercial™ Packaged Electric Cooling Unit, Rooftop, Series: K-Series™, 3 ton Cooling, 12.5 EER, 14 SEER, Scroll Compressor, 2.9 kW 208/230 V 60 Hz 1 ph, 40 A Fuse, 1140 cfm, R-410A, 74 dB, Multi-Speed Blower Motor, (1) 1/4 hp Motor, Steel, 38-7/8 in H x 47 in W x 85-1/4 in D
- Single-Zone VAV (Variable Air Volume) supply fan technology
- Up to 61% power savings over comparable units
- 29% better moisture removal for humidity control when compared to systems with conventional supply fan motors
- Eco-Last™ Coil System uses up to 52% less refrigerant, is up to 59% lighter, and has up to 20% fewer brazed joints than regular rooftop unit coils (standard on KC and KG models)
- Isolated compressor for quieter operation and easier service
- Easy-to-reach gas compartment for quick, simplified diagnostics and serviceability
- More than 100 field-selectable options ensure fast and easy installation
- High-pressure switch guards the compressor from extreme operating conditions
- 2nd generation major design sequence
- Standard cooling efficiency
- Direct drive blower
- (1) 1/4 hp 825 rpm outdoor coil fans
- 1/2 hp indoor blower
- (1) 10 in Dia x 10 in W blower wheel
- (4) 16 x 20 x 2 in disposable filter
- 1.7 FLA outdoor fan/3.9 FLA indoor blower motor
- 25 A minimum circuit
