Allied Commercial™ KGB060S4BM-Y
Allied Commercial™ K-Series™ | 5 Ton Cooling | 108 Single Heat | 3 phase | Rooftop Packaged Gas/Electric Unit
Manufacturer: Allied Air Enterprises
Brand: Allied Commercial™
Part #: 361968
MPN: KGB060S4BM-Y
UPC: 662551492644
CPN:
Min. Order Qty: 1
Qty Order Interval: 1
| AFUE Rating | : | 0.81 |
| Cooling Capacity | : | 60000 Btu/hr |
| Dimensions | : | 48-7/8 in H x 85-1/4 in W x 47 in D |
| Drive Type | : | Belt |
| EER Rating | : | 11.8 |
| Flow Rate | : | 1760 cfm |
| Frequency Rating | : | 60 Hz |
| Heat Input | : | 108000 Btu/hr |
| Heating Capacity | : | 108000 Btu/hr |
| Material | : | Steel |
| Motor Rating | : | (1) 1/3 hp |
| Number of Phase | : | 3 ph |
| Number of Speeds | : | 1 |
| Power Rating | : | 5 kW |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 14 |
| Series | : | K-Series |
| Sound Level | : | 79 dB |
| Type | : | Rooftop |
| Voltage Rating | : | 208/230 V |
| Warranty | : | 5 Years Limited |
Allied Commercial™ Gas/Electric Packaged Unit, Rooftop, Series: K-Series™, 5 ton Cooling, 108000 Btu/hr Heating, 208/230 V, 3 ph, 60 Hz, 5 kW, 0.81 AFUE, 11.8 EER, 14 SEER, R-410A, 108000 Btu/hr Heat Input, 1 Speed, 1760 cfm, 79 dB, Belt Drive, (1) 1/3 hp Motor, Steel, 48-7/8 in H x 85-1/4 in W x 47 in D
- Standard Cooling efficiency
- 2nd Generation major design sequence
- Single-Zone VAV (Variable Air Volume) supply fan technology
- Up to 61% power savings over comparable units
- 29% better moisture removal for humidity control when compared to systems with conventional supply fan motors
- Eco-Last™ Coil System uses up to 52% less refrigerant, is up to 59% lighter, and has up to 20% fewer brazed joints than regular rooftop unit coils
- Isolated compressor for quieter operation and easier service
- Easy-to-reach gas compartment for quick, simplified diagnostics and serviceability
- More than 100 field-selectable options ensure fast and easy installation
- High-pressure switch guards the compressor from extreme operating conditions
- 15-year limited warranty on stainless steel gas heat exchanger
- 10-year limited warranty on aluminized gas heat exchanger
- 3-year limited warranty on Eco-Last Coil System
- 1-Year Limited Warranty on covered components
- 1 stage medium gas heating
- 13.5 A rated load and 109 A locked load compressor, 2.4 A full load outdoor fan motor, 4.9 A full load indoor blower motor
- 0.75, 1.5 hp indoor blower motor
- (1) 1/3 hp 1075 rpm outdoor coil fan motor
